Swaraj
724 XM Orchard NT
New Holland
3032 Nx
Sonalika
Worldtrac 75
ENGINE |
Swaraj 724 XM Orchard NT |
New Holland 3032 Nx |
Sonalika Worldtrac 75 |
|---|---|---|---|
| HP Category | 30 HP | 35 HP | 75 HP |
| Engine Capacity | 1824 cc | 2365 cc | 3707 cc |
| Engine Rated RPM | 1800 RPM | 2000 RPM | 2200 RPM |
| Max Torque | - | - | |
| No of Cylinder | 2 | 3 | 4 |
| Air Filter | Dry type, Dual element with dust unloader | Oil bath type with Pre-cleaner | Dry type with air cleaner with precleaner & clogging system |
| Cooling System | Water Cooled with No loss tank | Water cooled | Water Cooled |
TRANSMISSION (GEARBOX) |
|||
|---|---|---|---|
| Clutch type | Standard Single dry friction plate (Diaphragm type) | Single Clutch | Double Clutch |
| Transmission type | Constant mesh | Constant Mesh AFD Side Shift | Synchromesh |
| Gear Level Position | - | - | Side Shift |
| Speed min-max | 2.2 - 23.3 kmph | 2.92 – 33.06 kmph | 1.95 - 36.46 kmph |
| Reverse speed min - max | 2.2 - 8.7 kmph | 3.61 – 13.24 kmph | kmph |
| Forward Gears | 6 | 8 | 12 |
| Reverse Gears | 2 | 2 | 12 |
| Rear Axle | - | Outboard Reduction | |
BRAKES |
|||
|---|---|---|---|
| Brake Type | Oil Immersed Brakes | Oil Immersed Multi Disc Brake | Oil Immersed Brakes |
| Turning radius with brake | NA | 2810 mm | |
STEERING |
|||
|---|---|---|---|
| Steering Type | Power Steering | Mechanical/Power Steering | Mechanical / Power Steering |
POWER TAKE OFF |
|||
|---|---|---|---|
| PTO type | 6 Spline | 6 Spline | Multi Speed PTO |
| PTO RPM | 540 | 540S | 540, 540E |
| PTO POWER | 21.1 HP | 34 HP | 63.75 HP |
FUEL CAPACITY |
|||
|---|---|---|---|
| Fuel Tank Capacity | 35 litres | 42 litres | 108.3 litres |
DIMENSION AND WEIGHT |
|||
|---|---|---|---|
| Weight | 1495 kg | 1750 kg | 2750 kg |
| Wheelbase | 1550 mm | 1930 mm | 2250 mm |
| Overall Length | 2900 mm | 3290 mm | |
| Tractor width | 1092 | 1660 | |
| Ground Clearance | 220 | 370 | 390 |
LIFTING CAPACITY (HYDRAULICS) |
|||
|---|---|---|---|
| Lift capacity in kg | 1000 kg | 1500 kg | 2500 kg |
| 3 Point linkage | Category- I and II | Automatic Depth & Draft Control, Lift- O-Matic, Response Control, Multiple Sensitivity Control, Isolator Valve. | Category - II |
| Hydraulic Controls | ADDC | ADDC | |
TYRE SIZE |
|||
|---|---|---|---|
| Front | 5.00 X 15 | 6.00 x 16 | 7.5 X 16 |
| Rear | 9.5 x 24 | 13.6 x 28 | 16.9 X 30 |
ADDITIONAL FEATURES |
||||
|---|---|---|---|---|
| Accessories | Tools,Bumper,Ballast Weight,Top Link,Canopy,Hitch,Drawbar | TOOLS,BUMPER,TOP LINK,CANOPY,HITCH,DRAWBAR | ||
| Other | Fuel efficient engine as per Bharat Trem-IIIA criterion, Rear view mirror, Adjustable vertical & horizontal side draft silencer, suitable for orchards, Transparent water separator | Heavy Duty Front Axle Support, Std.Driver Seat, Softek Clutch, Multisensing with DRC Valve, Tipping Trailer Pipe, 90 kg HD Front Bumper, Neutral Safety Switch, Antiglare Rear View Mirror, Semi Flat Platform | High torque backup,High fuel efficiency | |
WARRANTY |
|||
|---|---|---|---|
| Warranty | 2000 Hours / 2 year | 6000 Hours / 6 year | 2000+3000 hour Or 2 + 3 year |
Compare tractors like Swaraj 724 XM Orchard NT VS New Holland 3032 Nx and buy the best model according to your usage. The Swaraj 724 XM Orchard NT comes in 30 HP, whereas the New Holland 3032 Nx has a 30 HP engine. Along with this, the engine capacity of the Swaraj 724 XM Orchard NT tractor is 1824 CC, while New Holland 3032 Nx has 2365 CC engine capacity. While compare tractors online, you should check every feature of Swaraj 724 XM Orchard NT, and New Holland 3032 Nx. For instance, the Swaraj 724 XM Orchard NT has a 1000 KG lifting capacity, whereas the New Holland 3032 Nx has a 1500 KG lifting capacity which makes the tractor compatible with related equipment.
