Mahindra
575 DI
New Holland
3630 TX Plus+
Sonalika
Tiger 47
ENGINE |
Mahindra 575 DI |
New Holland 3630 TX Plus+ |
Sonalika Tiger 47 |
|---|---|---|---|
| HP Category | 45 HP | 50 HP | 50 HP |
| Engine Capacity | 2730 cc | 2991 cc | 3065 cc |
| Engine Rated RPM | 1900 RPM | 2300 RPM | 1900 RPM |
| Max Torque | - | - | 205 |
| No of Cylinder | 4 | 3 | 3 |
| Air Filter | Oil bath type | Dry type | Dry Type |
| Cooling System | Water Cooled | Water Cooled | Coolant Cooled |
TRANSMISSION (GEARBOX) |
|||
|---|---|---|---|
| Clutch type | Dry Type Single / Dual clutch | Double Clutch with Independent Clutch Lever | Single/Dual (Optional) |
| Transmission type | Partial Constant Mesh / Sliding mesh | Fully Constant mesh / Partial Synchro mesh* | Constant Mesh with Side Shifter |
| Gear Level Position | - | - | |
| Speed min-max | 29.5 kmph | 0.94 - 31.60 kmph | 39 kmph |
| Reverse speed min - max | 12.8 kmph | 1.34 - 14.86 kmph | kmph |
| Forward Gears | 8 | 8 | 12 |
| Reverse Gears | 2 | 2 | 12 |
| Rear Axle | - | - | |
BRAKES |
|||
|---|---|---|---|
| Brake Type | Dry Disc Brakes/ Oil Immersed (Optional) | Oil Immersed Multi Disc Brakes | Multi Disc Oil Immersed Brakes |
| Turning radius with brake | 3260 mm | 3190 mm | |
STEERING |
|||
|---|---|---|---|
| Steering Type | Mechanical / Power Steering | Power Steering | Power Steering |
POWER TAKE OFF |
|||
|---|---|---|---|
| PTO type | 6 Spline | Single PTO / GSPTO | 540/ Reverse PTO |
| PTO RPM | 540 | 540, Reverse, Ground speed | |
| PTO POWER | 39.8 HP | 46 HP | 43 HP |
FUEL CAPACITY |
|||
|---|---|---|---|
| Fuel Tank Capacity | 47.5 litres | 60 litres | 65 litres |
DIMENSION AND WEIGHT |
|||
|---|---|---|---|
| Weight | 1860 kg | 2080-2060 kg | |
| Wheelbase | 1945 mm | 2045-2045 mm | |
| Overall Length | 3570 mm | - mm | |
| Tractor width | 1980 | - | |
| Ground Clearance | 350 | 445-445 | |
LIFTING CAPACITY (HYDRAULICS) |
|||
|---|---|---|---|
| Lift capacity in kg | 1600 kg | 1700 / 2000 kg | 2000 kg |
| 3 Point linkage | Category - II | Category I & II | 1SA/1TA & 1DA* |
| Hydraulic Controls | ADDC | ADDC | |
TYRE SIZE |
|||
|---|---|---|---|
| Front | 6 X 16 | 7.5 X 16 / 9.5 X 24 | 6.0 x 16 / 6.5 x 16 / 7.5 x 16 |
| Rear | 13.6 X 28 / 14.9 X 28 | 14.9 X 28 / 16.9 X 28 | 14.9 x 28 |
ADDITIONAL FEATURES |
||||
|---|---|---|---|---|
| Drive type | 2WD | 2WD / 4WD | 2WD | |
| Accessories | Tools,Top Link | Hood, Bumper, Top link , Tool, Hook | ||
WARRANTY |
|||
|---|---|---|---|
| Warranty | 2000 hr/2 year | 6000 Hours / 6 year | 5000 hours / 5 year |
