Mahindra
Arjun Novo 605 DI-i-with AC Cabin
Swaraj
963 FE
Farmtrac
45
ENGINE |
Mahindra Arjun Novo 605 DI-i-with AC Cabin |
Swaraj 963 FE |
Farmtrac 45 |
|---|---|---|---|
| HP Category | 57 HP | 60 HP | 45 HP |
| Engine Capacity | 3531 cc | 3478 cc | 2868 cc |
| Engine Rated RPM | 2100 RPM | 2100 RPM | 2000 RPM |
| Max Torque | - | - | |
| No of Cylinder | 4 | 3 | 3 |
| Air Filter | Dry type with clog indicator | Dry type | 3 - stage pre oil cleaning |
| Cooling System | Forced circulation of coolant | Water Cooled | Coolant cooled |
TRANSMISSION (GEARBOX) |
|||
|---|---|---|---|
| Clutch type | Dry , Dual Clutch | Mechanically actuated double clutch (independent PTO) | Single / Dual |
| Transmission type | Mechanical, Synchromesh | Synchromesh | Fully constant mesh type |
| Gear Level Position | Side Shift | Side Shift | Center Shift |
| Speed min-max | 1.7 - 33.5 kmph | 0.90 – 31.70 kmph | 2.8 - 30.0 kmph |
| Reverse speed min - max | 3.2 - 18.0 kmph | 2.8 – 10.6 kmph | 4.0 -14.4 kmph |
| Forward Gears | 15 | 12 | 8 |
| Reverse Gears | 3 | 2 | 2 |
| Rear Axle | - | Planetary reduction | Straight Axle |
BRAKES |
|||
|---|---|---|---|
| Brake Type | Mechanical / Oil Immersed Multi Disc | Oil Immersed Disc Brakes | Oil Immersed Multi Disc Brakes |
| Turning radius with brake | NA | NA | 3200 mm |
STEERING |
|||
|---|---|---|---|
| Steering Type | Power Steering | Power steering with differential cylinder | Mechanical/Power Steering (optional) |
POWER TAKE OFF |
|||
|---|---|---|---|
| PTO type | SLIPTO | Multispeed & Reverse PTO | Single |
| PTO RPM | 540, 540E, 540R | 540, 540E | 540 @ 1810/1592 ERPM |
| PTO POWER | 50.3 HP | 53.6 HP | 38.3 HP |
FUEL CAPACITY |
|||
|---|---|---|---|
| Fuel Tank Capacity | 66 litres | 60 litres | 50 litres |
DIMENSION AND WEIGHT |
|||
|---|---|---|---|
| Weight | 2045-2045 kg | 2650 kg | 1950 kg |
| Wheelbase | 2145-2145 mm | 2210 mm | 2125 mm |
| Overall Length | 3660-3660 mm | 3730 mm | 3240 mm |
| Tractor width | - | 1930 | 1870 |
| Ground Clearance | 385-385 | 425 | 377 |
LIFTING CAPACITY (HYDRAULICS) |
|||
|---|---|---|---|
| Lift capacity in kg | 2200 kg | 2200 kg | 1500 kg |
| 3 Point linkage | Category - II | Category-2 with fixed type lower links | Single Acting Spool valve |
| Hydraulic Controls | ADDC | Live Hydraulics | ADDC |
TYRE SIZE |
|||
|---|---|---|---|
| Front | 7.5 X 16 | 7.50 x 16 | 6.00 x 16 |
| Rear | 16.9 X 28 | 16.9 X 28 | 13.6 x 28 |
ADDITIONAL FEATURES |
||||
|---|---|---|---|---|
| Drive type | 2WD / 4WD | 2WD | 2WD | |
| Other | Swaraj 963FE comes with a single piece bonnet , single lever operations that makes the harvesting application convenient, suspended pedals and side shift gear levers, New digital instrument cluster which has a service reminder feature and multi reflector lights | |||
WARRANTY |
|||
|---|---|---|---|
| Warranty | 2000 hr/2 year | 2000 hr/2 year | 5000 Hours 5 year |
Compare tractors like Mahindra Arjun Novo 605 DI-i-with AC Cabin VS Swaraj 963 FE and buy the best model according to your usage. The Mahindra Arjun Novo 605 DI-i-with AC Cabin comes in 57 HP, whereas the Swaraj 963 FE has a 57 HP engine. Along with this, the engine capacity of the Mahindra Arjun Novo 605 DI-i-with AC Cabin tractor is 3531 CC, while Swaraj 963 FE has 3478 CC engine capacity. While compare tractors online, you should check every feature of Mahindra Arjun Novo 605 DI-i-with AC Cabin, and Swaraj 963 FE. For instance, the Mahindra Arjun Novo 605 DI-i-with AC Cabin has a 2200 KG lifting capacity, whereas the Swaraj 963 FE has a 2200 KG lifting capacity which makes the tractor compatible with related equipment.
